| positioning accuracy: | 0.01 mm |
|---|---|
| Repeatability: | 0.005 mm |
| working desk size: | 625*450mm |
|---|---|
| T-slot dimensions: | 4T-12-120 mm |
| Maximum load: | 150 kg |
| X/Y/Z axis travel: | 600/400/170 mm |
|---|---|
| Gantry width: | 705 mm |
| Beam to workbench: | 300 mm |
| Spindle nose to worktable: | 90-260 mm |
| Door opening width: | 540 mm |
| Maximum feed speed G00: | 15 m/min |
|---|---|
| Maximum processing speed G01: | 10 m/min |
| X/Y/Z axis motor power: | 750W/750W/750W |
| Spindle motor power: | 3 kW |
|---|---|
| Maximum spindle speed: | 21000 rpm |
| Tool holder: | ER20(Φ3.17-Φ12) |
| Spindle diameter: | 85 mm |
| Power supply and total capacity: | 3P/380V/50Hz/9KVA |
|---|---|
| Machine weight: | 2100 kg |
| aspect: | 1910*1730*1910mm |
| Controller: | Syntec 21MA/Taiwan |
|---|---|
| AC servo motor (driver): | Yaskawa/Japan |
| Spindle inverter: | Innovation/China |
| Linear Guides: | 25 Hiwin, PMI/Taiwan |
| Ball Screw: | 2005/2005/2505 Hiwin, PMI/Taiwan |
| Electronic handwheel: | EHDW-BA5S-1 Future/Taiwan |
| Lubrication system: | YET-A2P2 ISHAN/Taiwan |
| Oil Cooler: | Opt.Parsonthor/China |
| air conditioner: | Opt.Parsonthor/China |
| Pneumatic system: | AirTac/Taiwan |
| Chip conveyor: | — |
| Water tank capacity: | 95L |
| Water pump power: | 220W |
| ATC Type: | Straight type |
|---|---|
| Air traffic control capabilities: | 6 items |
